Toyo/Super Action 1.5 Ton X 1.5M Lever Block | Model : LB-T1.5

Features :

• Superior Grade 100 load chain-Wafios link, Din standard.

• Forged and Heat Treated load Hooks with batch traceability and stretch indicators

• 360°handle rotation with stroke to ratchet indicators

• Double pawl Brake system

• Asbestos free Brake Linings

• Forged Safety Latch

• Sealed Roller Bearings

• 100% Load Tested to 1.5xWLL

• MBL of 400% of  WLL

• 2000 Cycle Batch Tes

Specifications :

• Model : LB-T1.5
• Capacity : 1.5 ton
• Standard lifting height : 1.5 m
• Running test load : 2.25 T
• Pulling efforts : 22 kg
• Chain fall : 1
• Load chain diameter : 6 mm
• net weight : 10.8 kg
• Dimensions :
• A : 172 mm
• B : 410 mm
• C : 52 mm
• D : 110 mm
• E : 380 mm
