T-Slot Kits (Multiple Sizes) Footlocker Pictures

#All

TITAN’s go-to REPLACE for advanced fixturing and workholding setups!

• Locks in machine T-slot for low profile clamping
• Makes fast set-ups possible right on the machine table
• Brass hex follows contour of unusual shaped parts

Kit Contents

• 4 T-Nuts
• 6 Fixture Clamps
• 2 Hex Keys

#38TSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 3/8″
• Screw Size: 1/4-20
• Max Torque: 6.2 ft-lb
• Holding Force: 800 lbs

Country of Origin: United States of America.

#716TSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 7/16″
• Screw Size: 5/16-18
• Max Torque: 8.3 ft-lb
• Holding Force: 800 lbs

Country of Origin: United States of America.

#12TSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 1/2″
• Screw Size: 3/8-16
• Max Torque: 20.8 ft-lb
• Holding Force: 2000 lbs

Country of Origin: United States of America.

#916TSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 9/16″
• Screw Size: 3/8-16
• Max Torque: 20.8 ft-lb
• Holding Force: 2000 lbs

Country of Origin: United States of America.

#58TSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 5/8″
• Screw Size: 1/2-13
• Max Torque: 45 ft-lb
• Holding Force: 3000 lbs

Country of Origin: United States of America.

#1116TSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 11/16″
• Screw Size: 1/2-13
• Max Torque: 45 ft-lb
• Holding Force: 3000 lbs

Country of Origin: United States of America.

#8MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 8.000mm
• Screw Size: M6
• Max Torque: 8.55 N.m
• Holding Force: 3558 N

Country of Origin: United States of America.

#10MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 10.000mm
• Screw Size: M6
• Max Torque: 8.55 N.m
• Holding Force: 3558 N

Country of Origin: United States of America.

#12MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 12.000mm
• Screw Size: M8
• Max Torque: 11.30 N.m
• Holding Force: 3355 N

Country of Origin: United States of America.

#14MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 14.000mm
• Screw Size: M10
• Max Torque: 28 N.m
• Holding Force: 8895 N

Country of Origin: United States of America.

#16MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 16.000mm
• Screw Size: M12
• Max Torque: 61 N.m
• Holding Force: 13340 N

Country of Origin: United States of America.

#18MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 18.000mm
• Screw Size: M12
• Max Torque: 61 N.m
• Holding Force: 13340 N

Country of Origin: United States of America.

#20MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 20.000mm
• Screw Size: M16
• Max Torque: 135 N.m
• Holding Force: 26680 N

Country of Origin: United States of America.

#22MTSlotKit

Technical Data

• Quantity: 1
• T-Slot Size: 22.000mm
• Screw Size: M16
• Max Torque: 135 N.m
• Holding Force: 26680 N

Country of Origin: United States of America.
